80m/Min Fiber Laser Cutting Machine With Rack Driving Mechanism

  • 1
  • 2

Brand Name : keyilaser

Place of Origin : China

MOQ : 1

Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram

Supply Ability : 2pieces/month

Delivery Time : 10~15 work days

Cutting speed : 0-40000mm/min

Cooling mode : Water Cooling

Cutting thickness : 0-30mm

Condition : New

Graphic format supported : DXF,AI,BMP,DST

Control software : AutoCAD

Application : Laser Cutting

Warranty : 2 Years

Color : Red with white on laser cutting machine

Power supply : 500W/700W/750W/800W/1000W/1200W/2000W

Type : Fiber Lasr Cutting

Contact Now

Fiber Laser Cutting Machine High Specialty Fiber Laser Cutting Machine Laser Power

1. SD-fiber-3O15b is an international standard fiber laser cutting machine for sheet and tube integration.
2. Tube sheet integrated cutting, easy to exchange, not only can cut flat plate,
3. Moreover, it can meet the user's requirements for cutting round and square tubes and forming the box.

- Tough construction with the same solid framework we use for all of fiber laser.
- User friendly Cypcut Windows CAD/CAM CNC control unit.
- Unique features:
• Very easy to operate.
• Quick and easy installation.
• Low investment and operating costs.
• The most cost-efficient solution for every requirement
Working Area
3000*1500mm
4000*1500mm
6000*1500mm
4000*2000mm
6000*2000mm
Laser Module
Fiber Laser Module
Laser Power
500-2000W
Driving Mechanism
High-precision rack drive
Max.Moving Speed
140m/min
Max.Cutting Speed
80m/min
Positioning Accuracy
0.03mm
Repeatability Accuracy
0.02mm
Min.Line Width
0.1mm
Cooling Mode
water cooling
80m/Min Fiber Laser Cutting Machine With Rack Driving Mechanism
80m/Min Fiber Laser Cutting Machine With Rack Driving Mechanism


About Shipping

1. Order processing?
Please allow a processing time of 12-24 hours for your order(s) to ship. Equipment orders will take up to 2 weeks before leaving our warehouse. (Order processing is done during normal weekdays only, no holidays or weekends.)

2. Shipping methods?
(1) Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
(2) Responsible for the damage during the shipping process, will change the damage part for you for free.

3. Order tracking?
Online order can be tracked by login to your account. Please allow 24 hours after order is shipped to see logging details.
If you need a tracking number for your order, please send an email to us with your order/invoice number.

4. Import/export tax, duty, GSM, Customs Clearance, and etc?
All import/export related expenses are sole responsibility of the buyer; charges will vary from country to country. Please consult with your local import experts or transportation carrier for more details.

5. Lost or Stolen packages?
Please report all lost or stolen packages to us at the earliest possible time. An investigation will be open soon after reporting the incident to us, and a final ruling will be issued by the carrier for the claim after 10-15 business days. A replacement package will be sent as soon as the claim is accepted by the responsible carrier.
